Blind hole 8mm external diameter 35mm K35 miniature rotary encoder
40mm leaf spring
Key Features of K35 servo motor encoder
Bearing life: 1.5x109 revs at rated load(100000hrs at 2500RPM)
Environmental temperature: Operating:-20 ～+80°；storage:-25 ～+90°
Vibration(endure): Amplitude 0.75mm,5-55Hz,2 hours for three axis
individually
Sock(endure): 490m/s2 ,11 ms three times for X,Y,Z direction
individually
Certification: CE
Top REV: 5000RPM
Mark to Space ratio: 45% to 55%
Shaft load: Radial 30N; Axial 20N
Some Related K35 encoder model number
K35-J12C2500/8B6 DC5V spring plate 35T40
K35-J12L2000/4B8 DC5V spring plate 35T29
K35-J3N2500/16B10 DC5-12V spring plate 35T29
K35-J3F1200B6 DC12-24V spring plate 35T29
K35-J6S2500/8B8 DC5V spring plate 35T29
K35-J6C2000B10 DC5V spring plate 35T40
K35-J6E720B6 DC8-30V spring plate 35T29
K35-J12C1000/4B8 DC5V spring plate 35T40
K35-J12L2048/6B10 DC5V spring plate 35T40
Specification
| Items | Basic parameters |
| Brand | HENGXIANG |
| Encoder type | Incremental encoder |
| External diameter | 35mm |
| Thickness | 35mm |
| Installation dimension | 40mm(spring plate 35T40); 29mm(35T29) |
| Hollow shaft type | blind hole |
| Hollow shaft diameter | 6mm,8mm;10mm |
| Resolution | 30;36;50;60;100;200;250;256;300;360;400;450;500;512;600;
1000;1024;1200;2000;2048;2500; 4096;5000 |
| 1000/4;1000/6;1000/8;1024/4;1024/6；1024/8；2000/4；2000/6；2000/8；2048/4；2048/6;2048/8；2500/4；2500/6；2500/8;4096/4;4096/6;4096/8;5000/4;5000/6;5000/8 |
| Output phase | Phase A+,B+,Z+,A-,B-,Z-,U+,V+,W+,U-,V-,W- |
| Supply voltage | DC5V & DC8--30V |
| Outlet type | Cable out from side |
| Output mode | NPN/PNP(Open Collector Output) |
| Voltage output |
| Push-pull output |
| line drive (26LS31) TTL |
| line drive(DC8-30V) HTL |
| TTL(DC5V) phase ABZ are back of phase UVW |
| Protection grade | IP50 |
| Cable length | 500mm |
Our Selling points
- Utility Model Patent Certificate
- Own brand and unique brand
- CE certification for all models
- Prompt delivery date
- 100% full inspection before shipment
- Customers from about 200 countries
- IS09001:2015 Certification
About Encoder Vibration
Vibration acting on an encoder always cause wrong pulse easily.
So we have to pay more attention to encoder working place.
The more pulse per round, the narrower groovy spacing of grating,
ore effect to encoder by vibration, when motor speed is low or even
stopped, vibration acting on encoder shaft or encoder shell would
cause grating vibration, in this way, encoder might show wrong
pulse signal.
