Lightweight Solid Shaft Encoder 4mm Axial Length 250 pulse CNC
Optical Encoder OSS-025-2HC encoder NPN open collector
Characteristics
Resolution:20;25;36;05050;60;100;200;250;256;300;360;400;500;512;600;625;720;1000;1024;1200;1250;1440;2000;2048;2500
Supply voltage: DC5V: DC8-30V
Environmental humanity: Operating and storage: 35~85%RH
(non-condensing)
Top response Frequency: 100 kHz Max
Shell Material: die cast aluminum
Bearing life: 1.5x109 revs at rated load (100000hrs at 2500RPM)
GND: not connect to encoder
Shaft Material: Stainless steel
Our Service
1. Quick response once received customer’s quotation query
2. Professional engineer team, to solve your problems at any time
3. Various encoder models to be selected
4. Short lead time
About our factory
1. Own brand of "HENGXIANG" encoder
2. Has ISO9001:2000 Quality Management System Certificate and CE
Certification
3. Passed Shanghai New and High-tech Achievements Transformation
Project.
4. Our target: Meeting Client's Requirement,Creating Social
value,serving clients atte
Company profile
Please email us directly or contact online service right now to get
the latest video, otherwise you could visit our YOUTUBE page.
Detail Parameter
| External dimensions | External diameter: 30mm |
| Thickness: 30mm |
| Shaft diameter: 4mm(D type) |
| Encoder type | Incremental encoder | |
| Output phase | Phase A,B,Z,A-,B-,Z- |
| Supply voltage | DC5V : DC8-30V |
| Outlet type | Cable out from side |
| Cable out from back |
| Output mode | NPN&PNP |
| Voltage output |
| Push-pull output |
| Difference output(TTL,HTL,RS422) |
| Environmental temperature | Operating temperature: -20~+80° (Non icing) |
| Storage temperature: -25~+85° (Non icing) |
| Environmental humanity | Operating and storage: 35~85%RH (non-condensing) |
| Protection grade | IP50 |
| Cable length | 1000mm |
Dimensions
Some Related S30 encoder model number
S30-J3N1000 DC5V
S30-J3F200 DC12V
S30-J2V10 DC5-12V
S30-J2F256 DC5-30V
S30-L4C500 DC5V
S30-L4E512 DC8-30V
S30-J6C1024 DC5V
S30-L6E1200 DC24V
S30-L1N2048 DC5-12V
S30-J1F2500 DC8-12V
S30-J3V1200 DC24V
S30-L3N1024 DC5-24V
S30-L3F600 DC12-24V
S30-J6C360 DC5V
Usage
FFS machine
VFFS machine
Packing machinery
Capsule filling machine
Pharmaceutical machine
VVVF motor
Servo motor
Drawing machine
VFD
Inverter
Variable frequency driver
Embroidery machine
Elevator
Printing machinery
Projector
Package
Each single encoder is packed into a single safe carton with
protecting bubble.
Then all encoders will be put into a bigger carton to prepare
shipment.
